Product Details:
|
| Model NO.: | ZZ33173567W | Emission Standard: | Euro 2 |
|---|---|---|---|
| Drive Wheel: | 6×4 | Engine Capacity: | ＞8L |
| Seats: | ≤5 | Horsepower: | 351-450hp |
| Tire Certification: | ISO | Tire Design: | Tubeless |
| Dumping Type: | After Dumping | Condition: | Used |
| Truck Type: | Dump Truck | Brand: | HOWO |
| Transport Package: | In Nude | Specification: | 5600x2300x1500 |
| Trademark: | HOWO | Origin: | China |
| HS Code: | 87042300 | Supply Ability: | 100 Set/Sets Per Month |
| Transmission Type: | Manual | Power: | Diesel |
| Load Capacity: | 21-30t | Shipping Cost: | Contact The Supplier About Freight And Estimated Delivery Time. |
| : | Support Payment In USD | Secure Payments: | Every Payment You Make At Made-in-china.com Is Protected By The Platform. |
| Refund Policy: | Claim A Refund If Your Order Doesn't Ship, Is Missing, Or Arrives With Product Issues. |
Howo dump truck is as versatile as your day to day challenges on the construction and mining site. Thanks to Sinotruk engine, it brings even more transport capacity and safety to your construction site. Making it a reliable and efficient partner for your work.
SINOTRUK's Howo dump truck series is specially designed for Mining and Construction. The HOWO dump truck is known for its fuel efficiency and loading capability (up to 40 tons or 25-30 cubic meters). It is considered a better choice in the market.
HOWO DUMP TRUCK LIFT SYSTEM
Howo dump truck use HYVA front lift system, It is lighter, faster, safer, and more efficient. It's designed to deliver higher efficiency and more reliable operation at a lower cost for applications such as mining, transportation, and construction.
Howo dump truck middle system use T type lifting mechanism cylinders, it is designed for compartment length of 4200mm to 6300mm and has the carrying capacity of 20tons to 25tons, and lifting angle within 46-56°.
| ITEM | 4×2 howo dump truck | 6×4 howo dump truck | 8×4 howo dump truck |
|---|---|---|---|
| Series | HOWO DUMP TRUCK | HOWO DUMP TRUCK | HOWO DUMP TRUCK |
| Number of tire | 6 wheel | 10 wheel | 12 wheel |
| Dimension (mm) | 6980×2496×3150 | 8400×2496×3400 | 10245×2496×3400 |
| Wheel base (mm) | 3800 | 3600+1350 | 1800+3500+1350 |
| Curb weight (kg) | 7950 | 12080 | 14860 |
| Max load (kg) | 18000 | 25000 | 30000 |
| Engine brand | SINOTRUK | SINOTRUK | SINOTRUK |
| Emission | EURO2-5 | EURO2-5 | EURO2-5 |
| Power | 290-336hp | 336-420hp | 336-420hp |
| Gearbox Model | HW15710 | HW19710 | HW19710 |
| Gearbox type | 10 Forward speed gear | 10 Forward speed gear | 10 Forward speed gear |
| Howo dump truck axle | HF7/ST16 | HF9/HC16 | HF9/HC16 |
| Howo dump truck tire | 12.00R20 radial tire | 12.00R20 radial tire | 12.00R20 radial tire |
| Howo dump truck cab | HW70 without sleeper | HW70 without sleeper | HW70 without sleeper |
| ITEM | 4×2 howo dump truck | 6×4 howo dump truck | 8×4 howo dump truck |
|---|---|---|---|
| Dump truck box LxWxH (mm) | 4190x2300x800 | 5600/5800x2300x1500 | 7300x2300x1500 |
| Volume | 7.7cbm | 19-20cbm | 25cbm |
| LIFT SYSTEM | Ventral lift | HYVA front lift | HYVA front lift |
| Floor Thickness (mm) | 8 | 8-12 | 8-14 |
| Side Thickness (mm) | 4 | 6-10 | 6-12 |
Products cover: tractors, dump trucks, trucks, mixers, sprinklers, tank trucks, sewage suction trucks, garbage trucks, wrecker trucks, refrigerated trucks, flatbed semi-trailers, low flatbed semi-trailers, pallet semi-trailers , Canglan semi-trailer, dump semi-trailer, oil tank semi-trailer, LPG semi-trailer, etc.
Jinan Belt-Way truck part Co., Ltd was established in 2008 by Mr Xu who have many years of truck parts factory experience.
Now company specialize in the production and export of automotive accessories. The main products include truck parts, cylinder block, crank shaft, diesel motor etc.
The company is located in one of the largest truck parts distribution centers -Jinan City, Shandong Province, where Sinotruk was located.
We take quality as our top priority and value long term cooperation. We have an experienced and high efficience team who understand and meet your needs. With high quality and reasonalbe price our products enjoy good market in Southeast Asia, Africa and Middle Est etc.
Jinan Belt-Way truck part Co., Ltd is a business partner that cares about you, your business and everybody that are a part of our cooperation. Taking care of our common future through sustainable work and social responsibilities are cornerstones in everything we do. We listen. We care. We act responsibly. Our Code of Conduct guides us in our daily work. Welcome to contact us.
1.Does your company is a factory or trade company?
We have a factory ourself,we are on this business for few years in China. Our factory is very famous in the Shandong China.
2.Whats the qualify assurance we provided and how do we control quality?
(1) Established a procedure to check products at all stages of the manufacturing process-raw materials,process materials,validated or tested materials finished goods ect. Beside,we have also developed a procedure which identifies the inspection and test status of all items at all stages of the manufacturing process.
(2)100% inspection in assembly lines. All controls, inspections,equipment,fixtures,total production resources and skills are inspected to ensure they consistently achieve the required quality levels.
3. What's your MOQ?
One unit trailer or truck.
4. Can you satisfy my special requirement?
Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity!
Contact Person: Freixu
Tel: +8615063333928
