Radial Tire Design 371HP HOWO Tipper Truck for ≤5 Seats from Sinotruk

Radial Tire Design 371HP HOWO Tipper Truck for ≤5 Seats from Sinotruk
Radial Tire Design 371HP HOWO Tipper Truck for ≤5 Seats from Sinotruk Radial Tire Design 371HP HOWO Tipper Truck for ≤5 Seats from Sinotruk Radial Tire Design 371HP HOWO Tipper Truck for ≤5 Seats from Sinotruk Radial Tire Design 371HP HOWO Tipper Truck for ≤5 Seats from Sinotruk Radial Tire Design 371HP HOWO Tipper Truck for ≤5 Seats from Sinotruk Radial Tire Design 371HP HOWO Tipper Truck for ≤5 Seats from Sinotruk

Large Image :  Radial Tire Design 371HP HOWO Tipper Truck for ≤5 Seats from Sinotruk

Product Details:
Place of Origin: China
Payment & Shipping Terms:
Delivery Time: Peak Season Lead Time: within 15 workdays, Off Season Lead Time: within 15 workdays
Payment Terms: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Contact Now

Radial Tire Design 371HP HOWO Tipper Truck for ≤5 Seats from Sinotruk

Description
Model NO.: ZZ3257N3647A Emission Standard: Euro 2
Drive Wheel: 6×4 Engine Capacity: ＞8L
Seats: ≤5 Horsepower: 351-450hp
Tire Certification: GCC, ISO Tire Design: Radial
Dumping Type: Front Lifting Style Condition: New
Product Name: Dump Truck Transport Package: Nude
Specification: 5600x2300x1500 Trademark: HOWO
Origin: Shandong HS Code: 8704109000
Supply Ability: 5000



China 10 Wheel New Dumper Truck Price 371HP 20 Cubic Meters Sinotruk HOWO Tipper Dump Truck For Sale







Product Description



 HOWO 6×4 Dump Truck
Driving Type Left Hand Driving
Cabin HW76
Engine Make: SINOTRUK
wd615.47
Transmission HW19712, 12F & 2R, with PTO
Steering ZF power steering, model ZF8118, hydraulic steering with power assitance
Front Axle HF9 SSteering with doubleT-cross section beam
Rear Axle AC16, 2×16000 KGSPressed axle housing, central single reduction with hub



reduction and with differential locks between wheels and axles.Ratio:5.73
Propeller Shaft Double universal joint propeller shaft with gear-shaped coupling flange
Chassis Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced



sub-frame all cold riveted cross members  Front suspension:10 semi-elliptic leaf

springs, hydraulic telescopic double-action shock absorbers and stabilizer Rear

suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer
Brake Service brake: dual circuit compressed air brakeParking brake (emergency brake):



spring energy, compressed air operating on front shaft and rear wheelsAuxiliary

brake: engine exhaust brake
Electrics Operating voltage: 24 V, negative grounded   Starter: 24 V,



5.4 Kw                        Alternator: 3-phase, 28 V, 1500 W                        Batteries: 2 x 12 V, 165 Ah   Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tires 12.00r20, radial tires with one spare tire.
Fuel Tank 300 L
Cargo Body 5600*2300*1500 mm, Floor 8 mm and side 6  mm,
Overall Dimension 8200*2550*3500 mm
